286S0041R

Steering rack

Steering Gear Type: Rack and Pinion Steering Gear, Total Length [mm]: 1110, Axle Joint Thread Size: M14, Left-/right-hand drive vehicles: for left-hand drive vehicles, Colour: grey, Operating Mode: Electric, Manufacturer part number: 286S0066, Manufacturer: RIDEX, EAN number: 4059191382040

Distance of mounting bores [mm]: 317, Steering Gear Type: Rack and Pinion Steering Gear, Supplementary Article / Supplementary Info Info 2: with steering bellows, Total Length [mm]: 1070, Axle Joint Thread Size: M14x1,5, Input shaft height [mm]: 140, Vehicle configuration line / variant: Electric assist, Left-/right-hand drive vehicles: for left-hand drive vehicles, Operating Mode: Electric, Manufacturer part number: 286S0009, Manufacturer: RIDEX, EAN number: 4059191382491

Pressure Line Connection Thread Size: M18x1,5, Backflow Connector Thread Size: M16x1,5, Mounting points diameter [mm]: 10,9, Input shaft height [mm]: 51, Input Shaft Diameter [mm]: 19, Left-/right-hand drive vehicles: for left-hand drive vehicles, Stroke [mm]: 174, Overall Length [mm]: 1506, Operating Mode: Hydraulic, Manufacturer part number: 286S0058, Manufacturer: RIDEX, EAN number: 4059191671649

Steering Gear Type: Rack and Pinion Steering Gear, Support plate diameter [mm]: 10, Supplementary Article / Supplementary Info Info 2: without coupling rod, Entry Thread Size: M18, Exit Thread Size: M16, Left-/right-hand drive vehicles: for left-hand drive vehicles, Vehicle Equipment: for vehicles with power steering, Overall Length [mm]: 670, Operating Mode: Hydraulic, Manufacturer part number: 286S0041, Manufacturer: RIDEX, EAN number: 4059191382224

Fitting Position: Front Axle Left, Front Axle Right, Front axle both sides, Rod/Strut: Suspension Rod, Length [mm]: 335, Material: Steel, Thread Size 1: M12x1,5, Thread Size 2: M12x1,5, Pipe Diameter [mm]: 10, Supplementary Article / Supplementary Info Info 2: with fastening material, Manufacturer part number: 3229S0007, Manufacturer: RIDEX, EAN number: 4059191322695

Spark Plug: 1 - Earthed Electrode, Nickel Middle Electrode, Unscrewable SAE connector, Electrode Gap [mm]: 0,8, Spanner Size: 16 mm, External Thread [mm]: 12, Thread Length [mm]: 19, Spark Position [mm]: 3, Thread Pitch [mm]: 1,25, Tightening Torque [Nm]: 23, Tightening angle [degrees]: 90, Manufacturer part number: 686S0015, Manufacturer: RIDEX, EAN number: 4059191685363

Filter type: Spin-on Filter, Outer Diameter [mm]: 76, 78, Height: 76, Thread Size: 3/4-16 UNF-1B, 3/4\"-16F, Bypass Valve Opening Pressure [bar]: 2,5, Supplementary Article / Supplementary Info Info 2: with one anti-return valve, Gasket outside diameter [mm]: 72, Gasket inside diameter [mm]: 63, Manufacturer part number: 7O0048, Manufacturer: RIDEX, EAN number: 4059191245413

Filter type: Spin-on Filter, Outer Diameter [mm]: 76, Height: 79, Connecting thread: M20x1,5, Supplementary Article / Supplementary Info Info 2: with one anti-return valve, Manufacturer part number: 7O0136, Manufacturer: RIDEX, EAN number: 4059191353385

Electrode Gap [mm]: 1,1, Spanner Size: 16 mm, External Thread [mm]: 14, Thread Length [mm]: 19, Spark Position [mm]: 3, Thread Pitch [mm]: 1,25, Tightening Torque [Nm]: 28, Number of pins: 1, Tightening angle [degrees]: 90, Manufacturer part number: 686S0009, Manufacturer: RIDEX, EAN number: 4059191451364

Electrode Gap [mm]: 0,7, Spanner Size: 16 mm, Thread Length [mm]: 19, Spark Position [mm]: 4, Thread Size: M 12 x 1,25, Connector type: Napf, Tightening Torque [Nm]: 23, Number of pins: 1, Manufacturer part number: 686S0083, Manufacturer: RIDEX, EAN number: 4059191980543

Fitting Position: Front Axle Right, Lower, Cone Size [mm]: 15,4, Thread Size 1: MM12X1,5R, Supplementary Article / Supplementary Info Info 2: with fastening material, Manufacturer part number: 2462S0042, Manufacturer: RIDEX, EAN number: 4059191326358

Thread Size: M10x1.25, Length 1 [mm]: 81,4, Length 2 [mm]: 18,5, Voltage [V]: 11, Spanner Size: 12, Manufacturer part number: 243G0039, Manufacturer: RIDEX, EAN number: 4059191694556
