82B1516

Fitment unknown

Brake disc

Fitting Position: Front Axle, Brake Disc Type: Vented, Brake Disc Thickness: 25,1, Height: 49,9, Material: Cast Iron, Surface: Uncoated, Outer Diameter [mm]: 312, Centering Diameter [mm]: 65,1, Number of Holes: 5/10, Wheel Bolt Bore Diameter [mm]: 15,4, Bolt Hole Circle Ø [mm]: 112, Minimum thickness [mm]: 22,0, Inner Diameter [mm]: 146,0, Machining: Untreated, No. of holes 2: 9, Bore Diameter [mm]: 15,3, Supplementary Article / Supplementary Info Info 2: with bolts/screws, without bolts/screws, Drilled: no, usable for vehicles to construction year: 2016/11, Manufacturer part number: 82B0031, Manufacturer: RIDEX, EAN number: 4059191312726

Fitting Position: Front Axle, Brake Disc Type: Vented, Brake Disc Thickness: 22, Height: 36,7, Material: Cast Iron, Surface: Uncoated, Outer Diameter [mm]: 255,7, Centering Diameter [mm]: 65, Number of Holes: 5/6, Wheel Bolt Bore Diameter [mm]: 15,7, Bolt Hole Circle Ø [mm]: 100, Machining: Untreated, Supplementary Article / Supplementary Info Info 2: without bolts/screws, Drilled: no, usable for vehicles to construction year: 2016/11, Manufacturer part number: 82B0004, Manufacturer: RIDEX, EAN number: 4059191312610

Fitting Position: Rear Axle, Brake Disc Type: solid, Brake Disc Thickness: 9,9, Height: 51,3, Material: Cast Iron, Surface: Uncoated, Outer Diameter [mm]: 253, Centering Diameter [mm]: 65, Number of Holes: 5/10, Wheel Bolt Bore Diameter [mm]: 15,1, Bolt Hole Circle Ø [mm]: 112, Machining: Untreated, Supplementary Article / Supplementary Info Info 2: without bolts/screws, Drilled: no, usable for vehicles to construction year: 2016/11, Manufacturer part number: 82B0018, Manufacturer: RIDEX, EAN number: 4059191312641

Spark Plug: 1 - Earthed Electrode, Nickel Middle Electrode, Unscrewable SAE connector, Electrode Gap [mm]: 0,8, 0,9, Spanner Size: 16 mm, Thread Length [mm]: 19, Thread Size: M14 x 1,25, Assy./disassy. by qualified personnel required!: , Manufacturer part number: 686S0003, Manufacturer: RIDEX, EAN number: 4059191451357

Fitting Position: Rear Axle, Brake System: TRW / LUCAS / GIRLING, Wear Warning Contact: not prepared for wear warning indicator, Supplementary Article / Supplementary Info: with accessories, with spring, Thickness: 17, Quantity Unit: Axle Set, Height: 52,9, Width [mm]: 87, for brake disc diameter [mm]: 249, Manufacturer part number: 402B0029, Manufacturer: RIDEX, EAN number: 4059191313075

Product line: Iridium TT, Spark Plug: 1 - Earthed Electrode, Iridium Middle Electrode, Spanner Size: 16 mm, Thread Size 1: 19, Tightening Torque [Nm]: 22, Diameter: 14, Weight [g]: 43, Manufacturer part number: 686S0034, Manufacturer: RIDEX, EAN number: 4059191685523

Filter type: Spin-on Filter, Height: 92, Thread Size: 3/4-16 UNF, Diameter 1 [mm]: 76, Diameter 2 [mm]: 71,5, Manufacturer part number: 7O0016, Manufacturer: RIDEX, EAN number: 4059191236374

Filter type: Filter Insert, Outer Diameter [mm]: 57, Inner Diameter [mm]: 21,5, Length [mm]: 106, Supplementary Article / Supplementary Info: with gaskets/seals, Manufacturer part number: 7O0044, Manufacturer: RIDEX, EAN number: 4059191237111

Filter type: Spin-on Filter, Outer Diameter [mm]: 76, Height: 79, Connecting thread: M20x1,5, Supplementary Article / Supplementary Info Info 2: with one anti-return valve, Manufacturer part number: 7O0136, Manufacturer: RIDEX, EAN number: 4059191353385

Filter type: Spin-on Filter, Outer Diameter [mm]: 76, 78, Height: 76, Thread Size: 3/4-16 UNF-1B, 3/4\"-16F, Bypass Valve Opening Pressure [bar]: 2,5, Supplementary Article / Supplementary Info Info 2: with one anti-return valve, Gasket outside diameter [mm]: 72, Gasket inside diameter [mm]: 63, Manufacturer part number: 7O0048, Manufacturer: RIDEX, EAN number: 4059191245413

Spark Plug: 2 - Earthed Electrode, Fixed SAE connector, Nickel Middle Electrode, Electrode Gap [mm]: 1,0, Spanner Size: 16 mm, External Thread [mm]: 14, Thread Length [mm]: 19, Spark Position [mm]: 5, Thread Pitch [mm]: 1,25, Tightening Torque [Nm]: 28, Number of pins: 2, Tightening angle [degrees]: 90, Manufacturer part number: 686S0007, Manufacturer: RIDEX, EAN number: 4059191685301

Thread Size: M10x1.25, Length 1 [mm]: 81,4, Length 2 [mm]: 18,5, Voltage [V]: 11, Spanner Size: 12, Manufacturer part number: 243G0039, Manufacturer: RIDEX, EAN number: 4059191694556
