Fitting Position: Front Axle, Brake Disc Type: internally vented, Surface: Coated, Height [mm]: 36,7, Brake Disc Thickness [mm]: 22,0, Outer Diameter [mm]: 256, Centering Diameter [mm]: 65,0, Number of Holes: 5, Bolt Hole Circle Ø [mm]: 100,0, Minimum thickness [mm]: 19,0, Inner Diameter [mm]: 134, Machining: High-carbon, Bore Diameter [mm]: 15,6, Supplementary Article / Supplementary Info Info 2: without bolts/screws, Drilled: no, usable for vehicles to construction year: 2016/11, Manufacturer part number: 82B0004, Manufacturer: RIDEX, EAN number: 4059191312610

Fitting Position: Rear Axle, Brake Disc Type: solid, Surface: Coated, Height [mm]: 51,6, Brake Disc Thickness [mm]: 10, Outer Diameter [mm]: 253, Centering Diameter [mm]: 65,0, Hole Arrangement/Number: 5/10, Wheel Bolt Bore Diameter [mm]: 15,5, Bolt Hole Circle Ø [mm]: 112,0, Inner Diameter [mm]: 140, Bore Diameter [mm]: 15,3, Supplementary Article / Supplementary Info Info 2: without bolts/screws, Drilled: no, usable for vehicles to construction year: 2016/11, Manufacturer part number: 82B0018, Manufacturer: RIDEX, EAN number: 4059191312641

Fitting Position: Rear Axle, Brake Disc Type: solid, Material: Grey Cast Iron, Surface: Coated, Height [mm]: 39,5, Brake Disc Thickness [mm]: 9, Outer Diameter [mm]: 232, Centering Diameter [mm]: 65,0, Hole Arrangement/Number: 05/06, Bolt Hole Circle Ø [mm]: 100, Minimum thickness [mm]: 7, Inner Diameter [mm]: 125, Bore Diameter [mm]: 16, Drilled: no, usable for vehicles to construction year: 2016/11, KBA Number (Germany): A1, Manufacturer part number: 82B0003, Manufacturer: RIDEX, EAN number: 4059191312597

Quantity Unit: Axle Set, Fitting Position: Rear Axle, Wear Warning Contact: not prepared for wear warning indicator, Supplementary Article / Supplementary Info: with spring, Thickness [mm]: 17,2, Height [mm]: 53, Width [mm]: 87, WVA Number: 23554, Supplementary Article / Supplementary Info Info 2: with anti-squeak plate, for brake disc diameter [mm]: 249, fulfils ECE norm: ECE-R90, Manufacturer part number: 402B0029, Manufacturer: RIDEX, EAN number: 4059191313075

Filter type: Filter Insert, Outer Diameter [mm]: 65,5, Height [mm]: 99, Inner Diameter [mm]: 26, Supplementary Article / Supplementary Info: with gasket/seal, with gaskets/seals, Manufacturer part number: 7O0013, Manufacturer: RIDEX, EAN number: 4059191352807

Quantity Unit: Axle Set, Fitting Position: Front Axle, Wear Warning Contact: incl. wear warning contact, with integrated wear sensor, Supplementary Article / Supplementary Info: Photo corresponds to scope of supply, Thickness [mm]: 20, Number of wear indicators [per axle]: 1, Height [mm]: 55, Width [mm]: 146, Supplementary Article / Supplementary Info Info 2: with anti-squeak plate, with piston clip, Warning Contact Length [mm]: 155, Manufacturer part number: 402B0033, Manufacturer: RIDEX, EAN number: 4059191313082

Filter type: High efficiency air filter (HEPA), Particulate Filter, Length [mm]: 215, Width [mm]: 265, Height [mm]: 21, Recommended change interval [km]: 20000, Manufacturer part number: 424I0080, Manufacturer: RIDEX, EAN number: 4059191329403

Electrode Gap [mm]: 0,8, Spanner Size: 20,8, External Thread [mm]: 14, Thread Length [mm]: 19, Spark Position [mm]: 3, Thread Pitch [mm]: 1,25, Tightening Torque [Nm]: 28, Number of pins: 1, Tightening angle [degrees]: 90, Manufacturer part number: 686S0010, Manufacturer: RIDEX, EAN number: 4059191451371

Filter type: Spin-on Filter, Outer Diameter [mm]: 102, Height [mm]: 125, Thread Size 1: M26X1.5, Manufacturer part number: 7O0083, Manufacturer: RIDEX, EAN number: 4059191237579

Electrode Gap [mm]: 1, Spanner Size: 16 mm, Product line: Industrial, Spark Plug: 1 - Earthed Electrode, Platinum Middle Electrode, with gasket seat, Thread Length [mm]: 26,5, Spark Position [mm]: 5, Thread Size: M14x1.25, Connector type: SAE, Packing Type: Box, Projection [mm]: 3,4, Resistor to [kOhm]: 9, Resistor from [kOhm]: 3, Tightening torque from [Nm]: 25, Manufacturer part number: 686S0051, Manufacturer: RIDEX, EAN number: 4059191685646

Fitting Position: Rear Axle, Brake Disc Type: solid, Surface: Oiled, Height [mm]: 65, Brake Disc Thickness [mm]: 12, Outer Diameter [mm]: 288, Centering Diameter [mm]: 68, Number of Holes: 5, Minimum thickness [mm]: 10, Supplementary Article / Supplementary Info Info 2: without ABS sensor ring, without wheel bearing, Drilled: no, Manufacturer part number: 82B0212P, Manufacturer: RIDEX PLUS, EAN number: 4067448072583

Fitting Position: Rear Axle, Brake Disc Type: Perforated, slotted, solid, Surface: Coated, Height [mm]: 65, Brake Disc Thickness [mm]: 12, Outer Diameter [mm]: 288, Centering Diameter [mm]: 68, Number of Holes: 5, Minimum thickness [mm]: 10,5, Tightening Torque [Nm]: 140, Supplementary Article / Supplementary Info Info 2: with bolts/screws, Drilled: yes, Manufacturer part number: 82B2783, Manufacturer: RIDEX, EAN number: 4064138213691
