82B0518

Fitment not confirmed

Brake disc

Fitting Position: Front Axle, Brake Disc Type: Vented, Brake Disc Thickness: 25,1, Height: 49,9, Material: Cast Iron, Surface: Uncoated, Outer Diameter [mm]: 312, Centering Diameter [mm]: 65,1, Number of Holes: 5/10, Wheel Bolt Bore Diameter [mm]: 15,4, Bolt Hole Circle Ø [mm]: 112, Minimum thickness [mm]: 22,0, Inner Diameter [mm]: 146,0, Processing: Untreated, No. of holes 2: 9, Bore Diameter [mm]: 15,3, Supplementary Article / Supplementary Info Info 2: with bolts/screws, without bolts/screws, Drilled: no, usable for vehicles to construction year: 2016/11, Manufacturer part number: 82B0031, Manufacturer: RIDEX, EAN number: 4059191312726

Fitting Position: Front Axle, Brake Disc Type: Vented, Brake Disc Thickness: 22, Height: 36,7, Material: Cast Iron, Surface: Uncoated, Outer Diameter [mm]: 255,7, Centering Diameter [mm]: 65, Number of Holes: 5/6, Wheel Bolt Bore Diameter [mm]: 15,7, Bolt Hole Circle Ø [mm]: 100, Processing: Untreated, Supplementary Article / Supplementary Info Info 2: without bolts/screws, Drilled: no, usable for vehicles to construction year: 2016/11, Manufacturer part number: 82B0004, Manufacturer: RIDEX, EAN number: 4059191312610

Fitting Position: Rear Axle, Brake Disc Type: solid, Brake Disc Thickness: 9,9, Height: 51,3, Material: Cast Iron, Surface: Uncoated, Outer Diameter [mm]: 253, Centering Diameter [mm]: 65, Number of Holes: 5/10, Wheel Bolt Bore Diameter [mm]: 15,1, Bolt Hole Circle Ø [mm]: 112, Processing: Untreated, Supplementary Article / Supplementary Info Info 2: without bolts/screws, Drilled: no, usable for vehicles to construction year: 2016/11, Manufacturer part number: 82B0018, Manufacturer: RIDEX, EAN number: 4059191312641

Filter type: Filter Insert, Outer Diameter [mm]: 65, Height: 69, Inner Diameter [mm]: 24,2, Supplementary Article / Supplementary Info Info 2: with seal ring, Supplementary Article / Supplementary Info: with gaskets/seals, Manufacturer part number: 7O0017, Manufacturer: RIDEX, EAN number: 4059191356003

Filter type: Spin-on Filter, Outer Diameter [mm]: 65, Height: 85, Thread Size: M 20 X 1.5, Inner Diameter 2 [mm]: 55,3, Bypass Valve Opening Pressure [bar]: 1, Supplementary Article / Supplementary Info Info 2: with one anti-return valve, Manufacturer part number: 7O0012, Manufacturer: RIDEX, EAN number: 4059191236480

Filter type: Filter Insert, Outer Diameter [mm]: 65, Height: 104, Inner Diameter [mm]: 33, Supplementary Article / Supplementary Info: with gaskets/seals, Manufacturer part number: 7O0116, Manufacturer: RIDEX, EAN number: 4059191353736

Fitting Position: Front Axle Left, Front Axle Right, Front axle both sides, Rod/Strut: Suspension Rod, Length [mm]: 335, Material: Steel, Thread Size 1: M12x1,5, Thread Size 2: M12x1,5, Pipe Diameter [mm]: 10, Supplementary Article / Supplementary Info Info 2: with fastening material, Manufacturer part number: 3229S0007, Manufacturer: RIDEX, EAN number: 4059191322695

Length [mm]: 130, Spanner Size: 10, Glow Plug Design: Pencil-type Glow Plug, after-glow capable, Fitting Depth [mm]: 28, Connector type: PIN, Tightening torque from [Nm]: 15, Cone Pitch: 63, Thread Size 1: M 10 x 1, Supplementary Article / Supplementary Info Info 2: without pressure sensor, Manufacturer part number: 243G0006, Manufacturer: RIDEX, EAN number: 4059191651467

Electrode Gap [mm]: 0,8, Spanner Size: 20,8, External Thread [mm]: 14, Thread Length [mm]: 19, Spark Position [mm]: 3, Thread Pitch [mm]: 1,25, Tightening Torque [Nm]: 28, Number of pins: 1, Tightening angle [degrees]: 90, Manufacturer part number: 686S0010, Manufacturer: RIDEX, EAN number: 4059191451371

Filter type: Spin-on Filter, Height: 66,5, Seal Ring Diameter [mm]: 62,0, Connecting thread: M20x1,5, Supplementary Article / Supplementary Info Info 2: with one anti-return valve, Diameter: 65,5, Valve Type: Overflow Valve, Net Weight [g]: 210, Manufacturer part number: 7O0026, Manufacturer: RIDEX, EAN number: 4059191236404

Filter type: Spin-on Filter, Outer Diameter [mm]: 76, 78, Height: 76, Thread Size: 3/4-16 UNF-1B, 3/4\"-16F, Bypass Valve Opening Pressure [bar]: 2,5, Supplementary Article / Supplementary Info Info 2: with one anti-return valve, Gasket outside diameter [mm]: 72, Gasket inside diameter [mm]: 63, Manufacturer part number: 7O0048, Manufacturer: RIDEX, EAN number: 4059191245413

Filter type: Spin-on Filter, Outer Diameter [mm]: 78, Height: 78,5, Thread Size: 3/4\" 16 UNF-2B, Bypass Valve Opening Pressure [bar]: 1, Quantity: 1, Manufacturer part number: 7O0075, Manufacturer: RIDEX, EAN number: 4059191236565
